CuZn36Pb3易切削铅黄铜合金是含铅高的铅黄铜，不能热态加工，可切削性极为优良，且有高的减磨性能，用于钟表结构件及汽车拖拉机零件。

Material CuZn36Pb3, mat. No. CW603N, is an unhardenable wrought alloy. to the comparable make CuZn36Pb3, mat. No. 2.0375 acc. to DIN 17660 : 1983-12 applies: High hardness and strength parameter are achievable by cold forming only. Thermal and electrical conductivity are lower than for the unleaded brass grade of the same Zn-content. Machinability is improved by Pb-addition. Corrosion resistance to water, several saline solutions and organic liquids is also lower than for unleaded alloys of the same zinc-content. Processing properties: warm forming: good cold forming: good machinability: very good hard soldering: moderately soft soldering: very good TIG-welding: unfavorable burnishing: very good Application: for thin-walled extruded profiles e.g. construction profiles, hand rails, for stair rails, for screw machine parts in watch and electrical industry as well as for precision mechanics and optics.

CuZn36Pb3化学成份：

铜 Cu ：62.0～65.0

锌 Zn：余量

铅 Pb：2.4～3.0

铅 Pb：2.4～3.0

硼 P：≤0.01

铝 Al：≤0.5

铁 Fe：≤0.10

铍 Sb ：≤0.005

铋 Bi：≤0.002

注：≤0.75(杂质)

CuZn36Pb3力学功能：

抗拉强度 σb (MPa)：≥390

伸长率 δ10 (%)：≥10

伸长率 δ5 (%)：≥12

注 ：棒材的纵向室温拉伸力学功能

试样尺寸：直径或对边距离5～20
